半导体光电子器件物理与技术
当前位置: 首页 > 研究生培养 > 电子科学与技术学科导师 > 半导体光电子器件物理与技术
姓名:魏志鹏(博导)
学历:博士
职称:教授
研究方向:半导体激光技术
邮箱:weizp@cust.edu.cn
主要学习、工作经历
1996.09-2000.07,吉林大学,物理系,理学学士
2002.09-2008.06,中国科学院长春光学精密机械与物理研究所,凝聚态物理专业,理学博士
2008.07-2010.01,新加坡南洋理工大学,博士后
2000.07-至今,长春理工大学,教师
2014.01-至今,长春理工大学,高功率半导体激光国家重点实验室,副主任
2015.09-至今,长春理工大学,教授
主要教学工作
硕士研究生课程《电子科学与技术发展趋势》和《半导体激光器原理》;
博士研究生课程《半导体激光器件物理》和《电子科学与技术前沿》。
主要科研工作

主要科研工作成果:

教学获奖:

1.2024年,教育部,“全国优秀教师称号

科研奖励:

1. 2023年,中央组织部,国家级科技创新领军人才;

2. 2024年,人社部、教育部,全国优秀教师;

3. 2024年,吉林省政府,吉林省技术发明一等奖;

4. 2021年,吉林省政府,吉林省科技进步奖一等奖;

5. 2020年,吉林省政府,吉林省突出贡献专家(省政府津贴);

6. 2023年,中国产学研合作促进会,中国产学研合作创新奖;

7. 2023年,吉林省科技厅,吉林省杰出青年基金获得者。

学术论文:

(1)中科院一区:3D-Heterojunction Based on Embedded Perovskite Micro-Sized Single Crystals for Fast Photomultiplier Photodetectors with Broad/Narrowband Dual-Mode, Advanced Materials, 影响因子32.1

(2)中科院一区:Interfacial -Electron Cloud Extension and Charge Transfer Between Preferable Single-Crystalline Conjugated MOFs and Graphene for Pulse Generation, Advanced Materials,影响因子32.1

(3)中科院一区:Self-Structural Healing of Encapsulated Perovskite Microcrystals for Improved Optical and Thermal Stability,Advanced Materials,影响因子32.1

(4)中科院一区:Bridging the van der Waals interface for advanced optoelectronic devices,Advanced Materials,影响因子32.1

(5)中科院一区:Built-In 3D-Heterojunction Optical Microcavity Based on an Embedded Microsize Single Crystal in Collaborative Dendritic Perovskite Microcrystals for Ultraviolet Narrowband Photodetectors, ACS Photonics, 影响因子7.5

(6)中科院一区:Controlled Synthesis of Pure-Phase GaAs Nanowires through Shear Tension,ACS Photonics,影响因子7.5

(7)中科院一区:Ultrahigh-performance and broadband photodetector from visible to shortwave infrared band based on GaAsSb nanowires, Chemical Engineering Journal, 影响因子13.3

(8)中科院一区:Enhancing performance of a GaAs/AlGaAs/GaAs nanowire photodetector based on the two-dimensional electron–hole tube structure,Nano letters,影响因子11.2

(9)中科院一区:Directional emissions from perovskite nanocrystals thin film enabled by metasurface integration through one step spin-coating process,Nano Research,影响因子10.3

(10)中科院一区:Perovskite/GaAs-nanowire hybrid structure photodetectors with ultrafast multiband response enhancement by band engineering,Photonics Research,影响因子7.3

(11)中科院二区:Photoresponse improvement of mixed-dimensional 1D-2D GaAs photodetectors by incorporating constructive interface states,Nanoscale,影响因子8.3

(12)中科院二区:Controlling the Random Lasing Action from GaAs/AlGaAs Axial Heterostructure Nanowire Arrays,Nanoscale,影响因子8.3

(13)中科院二区:Femtosecond-laser-induced Supra wavelength Two-Dimensional ZnO Microstructures for Multi-Wavelength Photodetector Devices,Optics Letters, 影响因子3.1

(14)中科院二区:High Frequency Mid-infrared Quantum Cascade Laser Integrated with Grounded Coplanar Waveguide Transmission Line,IEEE Electron Device Letters,影响因子4.1

(15)中科院二区:Unraveling the Discrepancy on Persistent Photoconductivity Between Organic Single-Crystal and Thin-Film Phototransistors,IEEE Electron Device Letters,影响因子4.1

(16)中科院二区:Van Der Waals Integration of Phase-pure 2D Perovskite Sheets and GaAs Nanowires for Self-driven Photodetector,Journal of Materials Chemistry C,影响因子5.7

(17)中科院二区:Very Long Wave Infrared Quantum Cascade Detector Based on Modular Band Structure,Chinese Optics Letters,影响因子3.3

(18)中科院二区:Gate-tunable the interface properties of GaAs-WSe2 (1D-2D) vdWs heterojunction for high-responsivity, self-powered photodetector,Applied Physics Letters,影响因子4.0

(19)中科院二区:Unraveling the Mechanism of the Light‐Triggered Synaptic Plasticity in Organic Photoelectric Synaptic Transistors, Advanced Electronic Materials, 影响因子5.3

(20)中科院二区:Emission-state transition in InGaAsSb/AlGaAsSb multiple quantum wells induced by rapid thermal annealing, Optics & Laser Technology,影响因子4.6

(21)中科院二区:Precise and smooth structure on InP fabricated by femtosecond laser direct writing-assisted wet etching, Optics & Laser Technology,影响因子4.6

(22)中科院二区:Effect of InAs insertion layer on the structural and optical property improvement of InGaAs/InAlAs multiple quantum wells, Journal of Alloys and Compounds,影响因子5.8

(23)中科院二区:Electrostatic discharge induced degradation of optical-electrical properties and defect evolution of GaAs-based oxide-confined VCSELs, Optics Express,影响因子3.2

(24)中科院二区:Air-Stable Self-Driven UV Photodetectors on Controllable Lead-Free CsCu2I3 Microwire Arrays,ACS applied materials & interfaces,影响因子8.3

(25)中科院二区:Enhanced photoresponsivity of a GaAs nanowire metal-semiconductor-metal photodetector by adjusting the fermi level,ACS applied materials & interfaces,影响因子8.3

(26)中科院二区:Room-Temperature Near-Infrared Lasing from GaAs/AlGaAs Core-Shell Nanowires Based on Random Cavity,ACS applied materials & interfaces,影响因子8.3

授权发明专利:

    (1)一种用MBE横向生长纳米线的方法,ZL202111636119.4,2023-12-26,中国

    (2)一种实时自校准痕量气体浓度的检测装置,ZL202111570147.0,2023-11-14,中国

    (3)一种多组分气体浓度检测装置及方法,ZL202111570140.9,2023-11-03,中国

    (4)一种具有高热导率的半导体衬底及其制备方法,ZL201911411742.3,2021-07-06,中国

    (5)一种调节GaSb纳米线探测器响应波长的方法,ZL201811411972.4,2021-03-09,中国

    (6)一种窄线宽半导体激光器,ZL201810000258.X,2020-12-22,中国

    (7)一种利用应力调控实现纯相GaAs纳米线的制备方法,ZL201810039796.X,2020-07-14,中国

    (8)一种垂直腔面发射半导体激光器制备方法,ZL201710352038.9,2020-05-15,中国

    (9)一种半导体光放大器,ZL201611100374.6,2019-12-10,中国

    (10)一种发光效率增强的半导体激光器,ZL201611091156.0,2019-09-27,中国

    (11)一种量子点带间级联激光器,ZL201610436288.6,2019-09-27,中国

    (12)一种提高n型GaSb基半导体激光器材料掺杂浓度的方法,ZL201810006341.8,2019-09-27,中国

    (13)基于能带调制的双重量子点敏化氧化物复合光催化材料,ZL201610108827.3,2019-06-28,中国

    (14)DETECTOR MATERIAL AND PREPARATION METHOD THEREOF,US11929446B2,2024-03-12,美国
